SC1462
Product inactive. Information on this page is for reference only.
Features
- Input supply voltage range of 1.65 V to 5.5 V
- Small size: 6-pin SOT-23 package
- Typical efficiency of
- 91% @ Vin = 2.5 V, Iout = 45 mA
- 94% @ Vin = 3.6 V, Iout = 55 mA
- Short-circuit and over-temperature protection
- 140 µA typical input current @ no load
- Sutdown current < 1 µA
- Designed to work with ceramic or tantalum capacitors
- Fixed frequency of 160 kHz
- All specifications rated over full temperature range (-40°C to +85°C)
- Cellular phones
- Handheld devices
Applications
Packaging
- SOT-23-6
Order Codes
- SC1462ISKTR: Package Minimum Tape & Reel Only
- SC1462ISKTRT: Lead-Free, RoHS and WEEE Compliant, Package Minimum Tape & Reel Only
