SC615A
Product inactive. Information on this page is for reference only.
Features
- Two Selectable Modes - Flash and Spotlight
- Up to 700mA Output - Flash Mode
- Up to 280mA Output - Spotlight Mode
- 500mA Over Temperature Range and Voltage Range - Flash Mode
- Spotlight mode set to 40% of Flash Current
- 3.0V to 5.25V Input Range
- External Flash Control Pin for Synchronization to a Camera Module or Graphics Controller
- Short Circuit, Over-Voltage, and Over-Temperature Protection
- Soft-Start Functionality
- Two Control Inputs for Maximum Versatility
- Shutdown Current < 2µA
- Micro Lead Package MLPD-10, 3mm x 3mm
- Mobile Camera Phones
- Digital Cameras
- PDAs with Built-in Cameras
Applications
Packaging
- MLPD-10 (3X3 mm)
Order Codes
- SC615AMLTRT: Lead-Free, RoHS and WEEE Compliant, Package Minimum Tape & Reel Only
