SC1202
Product is not recommended for new design.
Features
- Low dropout performance, 1.3 V max.
- Full current rating over line and temperature
- Fast transient response
- ± 2% total output regulation over line, load temperature
- Adjust pin current max. 90 µA over temperature
- Adjustable or fixed output voltages
- Line regulation 0.2% max.
- Load regulation 0.4% max.
- SOT-223 package. Fully WEEE and RoHS compliant
- Low-voltage microcontrollers
- Microprocessor I/O supplies
- 5 V to 3.3 V conversion for memory, ASIC, custom circuits, etc.
Applications
Packaging
- SOT-223
Order Codes
- SC1202CST-3.3TR: Package Minimum Tape & Reel Only
- SC1202CST.TR: Package Minimum Tape & Reel Only
- SC1202CST3.3TRT: RoHSCompliant, Package Minimum Tape & Reel Only
- SC1202CSTTRT: Lead-Free, RoHS and WEEE Compliant, Package Minimum Tape & Reel Only
