SC1564
Product inactive. Information on this page is for reference only.
Features
- VIN range: 2.7V to 5.5V
- Fixed 1.5V or adjustable output voltage
- 600mA output current
- Operate with ceramic capacitors
- 2μA quiescent current in shutdown
- No minimum load current requirement
- Over-current and over-temperature protection
- Reverse voltage protection
- 3mm x 3mm x 1mm MLPD-8 package ( WEEE and RoHS compliant )
- Personal digital assistants
- Battery powered systems
- Motherboards
- Peripheral cards
- PCMCIA cards
Applications
Packaging
- MLPD-8
Order Codes
- SC1564ML-1.5TRT: Lead-free package, fully WEEE and RoHS compliant, tape and reel only.
