Overview

The Gennum® GN1052 is a fully integrated silicon germanium BiCMOS transimpedance amplifier, providing wideband, low noise pre-amplification of signal current from a PIN photodiode or APD.

It features differential outputs. A decoupling capacitor on the supply is the only external component required.

Packaging

  • Bare Die

Order Codes

  • GN1052-CHIP

PB Free/ROHS

Learn More →

Features

  • Single +3.3V power supply
  • Power dissipation =180 mW (typ)
  • Input noise current = 1µA rms
  • Transimpedance gain = 4kΩ into a 100Ω load (differential)
  • Input current overload = 2.6 mA pk
  • Upper Bandwidth (-3dB) = 13GHz
  • Operates at OC-192 / STM-64 up to 11.3Gbps NRZ rates
  • Optimized for PIN photodiodes
  • Can be used with APD (0.4pF) at 10Gbps
  • RSSI (Receive Signal Strength Indicator)
  • Operating junction temperature range = -40 to +125°C

Applications

  • SONET/SDH-based transmission systems, test equipment and modules
  • OC-192 fibre optic modules and line termination
  • 10 Gigabit Ethernet
  • Fibre Channel
  • Serial data systems up to 11.3Gbps
