Overview
This Mbed shield features Semtech's LoRa® SX1261 and is a switchless design configured for 868MHz for Europe and 915MHz for North America frequency bands.
Features
- Based on SX1261
- PCB Layers: 4
- 32MHz Ref Clock: TCXO
- Region: Europe and North America
- Frequency Band: 868MHz and 915MHz
- Tx Out Power: 14dBm PCB
- Version Number: E460V01A
- RF Matching: Switchless design
- Single RF Module Part Number: SX1261MB1LDCS (Reference design only)
| Documents | Release Date | Type |  |
|---|---|---|---|
| AN1200-79: SX126x Switchless Design | 2024-02-23 | | |
| Documents | Release Date | Type | |
|---|---|---|---|
| SX1261/2 Switchless Reference Design | 2024-02-23 | ZIP | |
